55966 - 120A manual reset circuit breaker. (1pc)
120A surface mounting manual trip / reset circuit breaker. Higher the over current - the faster the trip time.
Specifications / features:
Single pole thermal circuit breaker
Ratings: 60A @ 30 VDC continuous
Interrupt Capacity: 3000A
Operating Temperature: –32°C to 82°C.
Housing: Thermoset plastic; UL rated 94VO; 155°C.
Complies with SAEJ1625
Indicator: A unique reset mechanism which provides visible indication of tripped condition.
Typically used in auxiliary and accessory circuits -- trucks, buses, RVs and marine applications. Others might include battery chargers and DC audio systems.
Sealed for engine compartment and bilge area application
